Description
This auxiliary control panel 52804 model AX10A2 is a single button pump control as used in Strong Spas and other brand hot tubs.
This aux control panel comes with 7 foot long cord and molex connector for newer Balboa equipment.
Topside ControlAX10A2, Auxiliary, 1-Buttonwith a Molex Plug
Overlay sold separately as needed. Labels available include:
Jets – see 12106
Jets 2 – see 40106
Aux – see 12107
Light – see 40108
Strong Spa 1 pump round label – BI12468O/L
This one button control allows for convenient access to a single spa function such as pump or light from a seating position further away from the main control panel.
Includes a 7ft cord with a 6-pin Molex style plug for newer Balboa control systems and comes without an overlay (overlay sold separately at links above as needed depending on label required)
Need a y-splitter cable? see 25257.
TSC AX10 Round A2 EL and BP
Note this is AX10A2 that controls pump 2.Per Balboa, the different versions of the AX10 1-button aux control panels have some programming in the topside control panel which makes each of these versions unique.These are specific to the pump or accessory they are controlling. AX10A1 controls pump 1. AX10A2 controls pump 2. A3 would control the blower, or pump 3.
