Description
- Two Speed
- 12 & 3 O’clock Conduit Entries
- 3-1/2″ Shaft Height
- 40C Ambient
- Four Thru Bolts on a 5.146 Bolt Circle
- Flex 48 LASAR Line Low Amp Start and Run with 48/56 Base Mounting
- 48/56 Base Mounting
- Threaded Shaft
- Rigid Base
Used On:
- Gecko Flo-Master XP/XP2/XP2E 48-Frame
- Jacuzzi Models L Pump Parts
- Flo-Master FMHP Series Side Discharge Spa Pump
- Gecko Flo-Master FMCP Series Center Discharge Spa Pump
Specifications:
- Phase: 1
- Output HP: 2-.25 Hp
- Output KW: 1.5 kW
- Voltage: 230 V
- Speed: 3450/1725 rpm
- Service Factor: 1
- Frame: X48Y
- Enclosure: Drip Proof
- Thermal Protection: Thermally Protected
- Ambient Temperature: 40 C
- Frequency: 60 Hz
- Current: 10.5/2.6 A
- Duty: Continuous
- Insulation Class: F
- UL: Recognized
- CSA: Y
- Number of Speeds: 2-2-VT
