Description
The CONTINENTAL CONTITECH 20042832 is a fractional horsepower cogged V-belt designed for light-duty power transmission applications in HVAC, agricultural, and industrial equipment. Built from high-traction rubber, this 5L-section belt delivers reliable torque transfer with reduced flex resistance thanks to its cogged construction. It carries an outside length of 27.0 inches and an internal length of 25.80 inches. Rated for operating temperatures from -40 degrees C to 140 degrees C, it handles demanding environments without premature wear. Abrasion-resistant and ozone-resistant materials extend service life in both indoor mechanical rooms and outdoor equipment enclosures.
This belt fits standard 5L-section sheaves and pulleys found in residential and light commercial HVAC blower assemblies, fan drives, and small motor-driven equipment. The cogged profile reduces heat buildup and improves flexibility around smaller-diameter pulleys, making it well suited for fractional horsepower motors common in air handlers, condensing units, and similar equipment. HVAC technicians, equipment mechanics, and facilities maintenance personnel typically handle installation of this belt type. The belt number designation is 5L270, which cross-references to standard industry sizing charts.
Key Features
- Cogged construction reduces bending resistance and heat buildup on small-diameter pulleys
- High-traction rubber compound provides consistent grip and torque transfer
- Abrasion-resistant and ozone-resistant for extended service life
- Wide operating temperature range: -40 degrees C to 140 degrees C
- 5L section with 27.0-inch outside length and 25.80-inch internal length
- Fractional horsepower rating suits light-duty HVAC and fan drive applications
Compatibility
Designed as an OEM-style replacement for standard 5L-section V-belt drives in fractional horsepower HVAC blower, fan, and motor applications. Belt number 5L270 cross-references to industry-standard 5L270 sizing.
Installation Notes
Always de-energize and lock out the equipment before removing or installing a drive belt. Loosen the motor mount or tensioner to relieve belt tension before removal, and do not pry or force the belt over sheave flanges, as this can damage belt cords. After seating the new belt, adjust tension to manufacturer specifications for the drive system and verify alignment of sheaves before restoring power. Inspect sheave grooves for wear or damage during each belt replacement.
Technical Specifications
- Belt Section: 5L
- Belt Number: 5L270
- Style: Fractional Horsepower V-Belt
- Belt Type: Cogged
- Outside Length: 27.0 inches
- Internal Length: 25.80 inches
- Material: High-Traction Rubber
- Maximum Working Temperature: 140 degrees C
- Minimum Working Temperature: -40 degrees C
- Resistance Features: Abrasion-Resistant, Ozone-Resistant
- Weight: 0.19 pounds
- UNSPSC Code: 26111800
Standard Information
- Brand: CONTINENTAL CONTITECH
- Manufacturer Part Number: 20042832
