Description
ASB844 Motor, US Motor, 3.0hp, 208-230v, 56YFr, SQFL, Full Rate, PE
The U.S. MOTORS ASB844 is a 1 Speed Pool/Spa Pump 56Y ODP Square Flange Motor. It runs at 3.45THP and 208-230V 60Hz. Square Flange Pump Motors are the most common motor frame used today. These frames attach directly to the pump.
Square Flange Pool & Spa Motor – Full Rated, Premium Efficiency
Switchless Design, 6.5″ Frame Diameter, Category “S”
FEATURES:
- Two Compartment
- 1081 Design
- Open Dripproof
- 303 Stainless Steel Shaft
- Shaft Threads – 1/2-20 UNF-2A
- Voltage Selection Device (Dual Voltage Only)
- Switchless Design
- 6.5″ Diameter Frame
- Triple Bearing Protection
- Continuous Duty
- Sealed Ball Bearings
- Class B Insulated
- Thermally Protected
- 50°C Ambient
- Discount Symbol: DS-FPS
