Description
The PANDUIT FX2ERLNSNSNM031 is a 2-fiber OM3 multimode duplex fiber optic patch cord terminated with LC connectors on both ends. Built with a 1.6mm simplex-style jacket rated OFNR (Optical Fiber Nonconductive Riser), this cord is designed for structured cabling installations in commercial and enterprise environments. The OM3 multimode fiber core supports high-bandwidth applications including 10 Gigabit Ethernet and supports laser-optimized transmission. Network technicians and low-voltage cabling contractors install this patch cord to interconnect switches, patch panels, transceivers, and active equipment in data centers, server rooms, and telecommunications closets.
This patch cord is suited for riser-rated pathways in multi-story commercial buildings where OFNR jacket materials meet NEC Article 770 riser requirements. The duplex LC form factor is widely used in SFP and SFP+ transceiver applications. The 1.6mm jacket diameter is a compact alternative to standard 2mm duplex cords, making it easier to manage in high-density patching environments. Low-voltage cabling technicians and data network installers are the primary trade personnel for this application.
Key Features
- OM3 multimode fiber supports 10 Gigabit Ethernet and laser-optimized transmission
- Duplex LC connectors on both ends for use with SFP and SFP+ ports
- 1.6mm OFNR-rated jacket meets NEC Article 770 riser installation requirements
- 2-fiber construction for duplex bidirectional data transmission
- Compact jacket diameter simplifies routing in high-density patch environments
Compatibility
Designed as an OEM-style patch cord for use with duplex LC-compatible fiber optic panels, switches, and transceivers in OM3 multimode structured cabling systems.
Installation Notes
Installation should be performed by a qualified low-voltage cabling technician familiar with fiber optic handling practices. Power down or disable active ports on connected equipment before connecting or disconnecting fiber patch cords to avoid eye hazard from laser light sources. Avoid bending the cord beyond its minimum bend radius, and do not exceed rated pulling tension during routing. Fiber end-face cleanliness should be verified with an appropriate inspection scope before mating connectors.
Technical Specifications
- Fiber Type: OM3 Multimode
- Number of Fibers: 2
- Jacket Diameter: 1.6mm
- Connector Type: LC Duplex
- Jacket Rating: OFNR (Optical Fiber Nonconductive Riser)
- Unit of Measure: Each
- Quantity Per Unit: 1
Standard Information
- Brand: PANDUIT
- Manufacturer Part Number: FX2ERLNSNSNM031
