Description
The PANDUIT FZ2ELLNSNSNM003 is an OM4 multimode duplex fiber optic patch cable designed for high-density structured cabling installations. It features a 1.6mm round LSZH (Low Smoke Zero Halogen) jacket, LC duplex connectors on both ends, and a 2-fiber construction. The LSZH jacket meets stringent fire safety requirements by limiting toxic smoke and halogen gas emissions, making this cable appropriate for enclosed spaces such as data centers, equipment rooms, and plenum environments where air handling is a concern. Licensed low-voltage cabling technicians and data center infrastructure teams are the primary installers of this cable type.
This patch cable is suited for backbone and horizontal runs in enterprise and commercial structured cabling systems operating on OM4 multimode fiber infrastructure. OM4 glass supports high-bandwidth applications including 10G, 40G, and 100G Ethernet over appropriate distances. The duplex LC configuration is standard for SFP and SFP+ transceiver ports found in switches, routers, fiber media converters, and optical distribution frames. The 1.6mm jacket diameter keeps bend radius manageable in congested patch panels and cable managers.
Key Features
- OM4 multimode fiber supports 10G, 40G, and 100G Ethernet applications
- Duplex LC connectors compatible with SFP and SFP+ transceiver ports
- 1.6mm LSZH jacket reduces toxic smoke and halogen emissions in low-smoke-zero-halogen-rated environments
- 2-fiber construction for standard duplex bidirectional optical links
- PC (Physical Contact) polish on connector ferrules for reliable low-loss mating
Compatibility
Designed as an OEM-style patch cable for use with LC duplex port equipment on OM4 multimode fiber networks in structured cabling systems.
Installation Notes
Installation should be performed by a qualified low-voltage cabling technician familiar with TIA-568 structured cabling standards. Inspect ferrule end faces for contamination before mating and clean with appropriate fiber optic cleaning tools prior to connection. Avoid exceeding the minimum bend radius of the cable during routing through cable managers and patch panels. Do not overtighten cable ties or fasteners against the jacket, as this can induce microbending losses in the fiber.
Technical Specifications
- Fiber Type: OM4 Multimode
- Fiber Count: 2-Fiber Duplex
- Connector Type: LC Duplex
- Polish Type: PC (Physical Contact)
- Jacket Diameter: 1.6mm
- Jacket Material: LSZH (Low Smoke Zero Halogen)
- Unit of Measure: EA
- Quantity Per Unit: 1
Standard Information
- Brand: PANDUIT
- Manufacturer Part Number: FZ2ELLNSNSNM003
