Pentair EQ Series 1-Phase Motor 230V 60Hz 7.5 HP | 357066S

Description

This Pentair 357066S is an exact OEM replacement motor built exclusively for Pentair EQ750 commercial pool pumps, restoring full 7.5 HP circulation without replacing the entire pump system. Operating on standard 230V, single-phase, 60 Hz electrical service, the unit draws 30.4 amps through a durable 213JMZ frame fitted with an Open Drip Proof (ODP) enclosure. Designed for continuous commercial-duty operation, its specialized JMZ mounting configuration ensures precise alignment with compatible EQ Series pump wet ends while maintaining optimal airflow and thermal management in outdoor equipment pads.

System Specifications

• Model & Frame: 357066S / 213JMZ
• Performance: 7.5 HP, single-speed, 30.4A rated load
• Power Requirements: 230V, 60 Hz, single-phase
• Enclosure: Open Drip Proof (ODP)
• Dry Weight: 137 lb

Verify electrical configuration before purchase: this motor functions strictly on single-phase power and will not operate in three-phase EQK750 setups. The package contains the electric motor assembly only; wet-end housings, impellers, diffusers, and mounting brackets must be retained from the existing equipment. Professional installation is required to safely isolate service power, secure the motor base, and replace the mechanical shaft seal during reassembly to prevent future leakage around the new armature. Backed by Pentairs standard one-year manufacturer warranty, this OEM unit delivers the exact rotational torque and thermal dissipation characteristics engineered for high-volume commercial pool circulation.
