Pleatco ULTRA-A9-PAK4 + Jandy CL/CV 460 Tank O-Ring Bundle | ULTRA-A9-PAK4+O-524-BAGGED
Service bundle for Jandy CL/CV 460 cartridge filters: Pleatco ULTRA-A9-PAK4 4-pack cartridges plus Jandy R0357800 / Aladdin O-524 tank O-ring to restore flow and clamp sealing.
Features
- Built for Jandy CL460 / CV460 systems (A0558000 / PJAN115 footprint)
- ULTRA-A9-PAK4 uses Pleatco Ultra media with PurePleat, point-bonded fabric & Free-Flow core
- Each cartridge approx. 7-1/8″ diameter, 115 sq ft, 3″ open top and bottom
- Replaces Jandy A0558000 and aftermarket PJAN115, C-7468, FC-0810 cartridges
- O-524 tank O-ring replaces Jandy R0357800 for CL/CV/DEL/DEV tank lids
- Tank seal dimensions around 21-15/16″ ID 23″ OD 9/16″ cross-section
This bundle is the straightforward way to get a CL/CV 460 filter back in shape. The Pleatco ULTRA-A9-PAK4 cartridge pack is an advanced upgrade over standard PJAN115 elements, with Ultra media designed for better dirt holding and lower system pressure. The Aladdin O-524 tank O-ring is the correct replacement for Jandy R0357800, sealing the lid and body under the clamp band so you dont fight air leaks or weeping at the joint after cleaning.
Replace worn media and a flattened gasket at the same time and youll see more stable pressure, better flow, and cleaner water without the nuisance leaks.
Pro Tip
Never pressure-wash cartridgesuse low-pressure water only. Before installing the new O-ring, clean the groove and tank lips, then lube the gasket lightly and seat it without twisting. Tighten the band evenly around the tank and bleed air fully on restart, then inspect the band area at operating pressure.
Related Parts
- Pleatco PJAN115-PAK4 Standard Cartridge Set | PJAN115-PAK4
- Jandy R0357800 Tank O-Ring Only | O-524-BAGGED
- Magic Lube PTFE O-Ring Lubricant | 630
Technical Specifications
| SKU | ULTRA-A9-PAK4+O-524-BAGGED (bundle) |
| UPC or GTIN | ULTRA-A9-PAK4: 812043683900; O-524-BAGGED: 601402193323 (Aladdin GTIN) |
| Brand | Pleatco (cartridges) + Aladdin Equipment Co. (O-ring) |
| Product Type | Filter cartridges (4-pack) + filter tank O-ring bundle |
| Size / Connection | Cartridges: ~7-1/8″ dia, 3″ open top/bottom; O-ring: Jandy R0357800 tank seal for CL/CV/DEL/DEV filters |
| Materials | Point-bonded polyester media with plastic cores/end caps; elastomer tank O-ring |
| Power Source | N/A |
| Compatible Product(s) | Jandy CL460 / CV460 (A0558000 / PJAN115 footprint) and other Jandy filters using R0357800 tank O-ring |
| Dimensions/Weight | Cartridge body ~7-1/8″ ~27″ L (115 sq ft each); O-ring ~21-15/16″ ID 23″ OD 9/16″ cross-section; bundle weight N/A |
| Warranty | N/A (see Pleatco and Aladdin terms) |
